AzarPixel proudly presents the Lighthouse Supervisor LH. This magnificent, powerful LED processor can include most of the expert user’s requirements. It offers a wide range of input ports, smooth high-resolution processing capabilities, and convenient control options.
This processor empowers the delivery of dynamic, engaging content with unmatched ease and efficiency. It offers two DVI and a VGA for outputs. It delivers superior image scaling by using advanced video processing technologies and can handle resolutions up to 1280×1024@60Hz through DVI ports and supports input rates up to 1200×1024@75Hz.
A comprehensive suite of ports handles diverse media, making it ideal for live events and concerts. These include multiple BNC connectors for CVBS and SDI inputs, as well as dedicated DVI and S-Video ports. Content can also be synchronized through REF ports.
The Supervisor LH provides flexible control options for maximum convenience. In addition to the front panel buttons, users can control the device via a PC using Ethernet or RS232. This remarkable controller is an affordable option that operates precisely with a 100-240VAC input voltage and 25W of low power consumption in extreme ambient temperatures ranging from 0°C to +40°C.
Lighthouse is well known for creating excellent digital signs, display panels, and LED control systems. Since it is regarded by experts globally and continues to improve industry standards in performance, dependability, and customer service, it is a reliable partner for businesses and roll players searching for cutting-edge LED display technology. Professional clients have been drawn to it for a variety of uses, including broadcasting, entertainment, and signage.
Key Features of Supervisor LH
Input
- 1x DVI Interface
- 2x SDI Interfaces
- 1x BNC 75ohm Connector (CVBS A)
- 1x Yellow Coded Phono Connector (CVBS B)
- 1x 4-way Mini-DIN Connector (S-Video)
- 2x BNC 75ohm connectors (S-Video)
- 5x BNC 75ohm connectors (for YPbPr, YUV or GBR video formats)
- 1x BNC 75ohm connector (Sync Reference Signal)
Output
- 2x DVI interfaces
- 1x VGA interface
- 1x BNC 75ohm connector (Sync Reference Signal)
Control
- 1x 9-way D connector (DIG REF/LINK IN for cascading)
- 1x 9-way D connector (DIG REF/LINK OUT for cascading)
- 1x LAN Interface (Wired network control)
- 1x RS-422/485 Interface
- 3x RS-232 interfaces (RS-232A, RS-232A, GPI/O)
Advanced Features
- Static zoom, aspect ratio, and picture position controls
- Auto-adaptive film and video processing
- Synchronizer with HD/SD master/slave Genlock
- Digital proc-amp and gamma controls 8 user memories
- Cascading
Dimensions (L*W*H)
- 483mm * 413mm * 134mm
| Weight | 15.1 lbs |
|---|---|
| Dimensions | 19.69 × 18.9 × 5.51 in |
| Max Input Resolution | 1920×1080@60Hz |
| Supported Resolutions For Input | 1200×1024@75Hz, 1280×1024@60Hz, 1920×1080@(23.98/24/25/29.97/30/60)Hz, 1920×1035@60Hz, 1280×720@59.9Hz |
| DVI Out | 2 |
| VGA Out | 1 |
| SDI | 2 |
| YPbPr | 1 |
| S Video | 3 |
| CVBS | 2 |
| Genlock In Loop | 1 |
| RS232 | 4 |
| UART In Out | 1 |
| Cascading | Supported |
| Net Weight Kg | 8 |
| Input Voltage Range | 100-250VAC |
| Max Power Consumption | 150W |
| Working Temperature Range | 0 °C to +40 °C |
| USB Playback | NO |
| Standard Certification | EN55103, EN60950, FCC Part 15, UL1419 |
| Others | 2 Additional BNC (H/V Sync) Connectors, Color, Saturation, Gamma, and Brightness Adjustment, Manual & Auto Screen Adjustment, Save up to 8 customizable display parameters and presets |
