NovaStar MSD300 Sending Card

Azar Pixel introduces the NovaStar MSD300, a compact and dependable sending card designed to deliver high-quality control for your LED displays. It supports a single-link DVI input connector which supports resolutions up to 1920×1200@60Hz and offers customized resolutions with a maximum width of 3840 pixels and a height of 1920 pixels. The card also includes an audio input for synchronized audiovisual performance.

In addition to the dual Gigabit Ethernet output ports and Ethernet redundancy, this card can handle up to 1,300,000 pixels on your display modules. Communication and configuration are simplified via a USB Type-B port, and UART connectors enable flexible cascading for large LED display arrangements.

The card will deliver more vivid and accurate visuals thanks to NovaStar’s advanced pixel-level calibration technology for efficient calibration and includes a light sensor input for automatic brightness adjustment based on ambient lighting.

Designed to operate reliably in temperatures from -20°C to +75°C, the MSD300 is suitable for both indoor and demanding outdoor environments. It meets EMC, RoHS, PFoS, and FCC certifications, ensuring compliance with international quality and standards.
