Lightlink JPS200P(4.5V)-F Power Supply (4.5V, 40A)
$63.62
8 in stock
| Minimum Qty | Discount |
|---|---|
| 15 + | 3% |
| 30 + | 5% |
| 45 + | 7% |
In Stock – Ships Today from Carrollton, TX
US Stock
Same-day shipping or store pickup
Easy Returns
60-day no-questions-asked return
Free Phone Support
Free online technical assistance
The Lightlink JPS200P (4.5V)-F is an enclosed power supply perfect for A/V and LED equipment, and industrial applications demanding a stable dependable performance, thanks to its excellent ±1% load regulation.
This AC/DC, compact JPS200P (4.5V)-F converts wide-range 100-240 VAC inputs to consistent output channels at 4.5V with an adjustable 4.4-4.6V range, delivering up to 40A. It provides a rated 180W output power with 88% efficiency for optimal operation.
The compact JPS200P (4.5V)-F offers reliable long-term performance in demanding environments. Natural air convection cooling and the DIN connectors for input and output ensure secure connections and withstand frequent use. The user-friendly design allows easy plugging and unplugging; it operates reliably in adverse temperatures from -30°C to +50°C.
In addition to the comprehensive protections such as overload, short circuit (self-recovery), and under-voltage protections, it is certified by EN55024, IEC 61000-4-2/3/4/5/6/8/11/29, 61000-3-2/3, GB/T 13722-92, and YD/T 732-95 allowing the equipment to comply with the global energy requirements.
Key Features of JPS200P (4.5V)-F
- Type of Power Supply: AC to DC
- Packaging: Enclosed
- Input Voltage Range: 100 – 240VAC
- Adjustable Output Voltage: Yes (4.4 – 4.6V)
- Output Voltage: 4.5V
- Output Rated Current: 40A
- Output Rated Power: 180W
- Protections: Under Voltage Protection, Over Current Protection, Short Circuit Protection
- Dimensions (L*W*H): 145mm * 78mm * 26mm
| Weight | 0.99 lbs |
|---|---|
| Dimensions | 5.71 × 3.07 × 1.02 in |
| Input Voltage Range | 100-240V |
| Input Frequency Range | 47-63Hz |
| Input Current | ≤3A |
| Efficiency | 88% |
| Output Voltage | 4.5V |
| Adjustable Output Voltage | Yes |
| Output Rated Current | 40A |
| Output Rated Power | 180W |
| Max Ripple And Noise | 200 mVp-p |
| Output Voltage Tolerance | 2% |
| Short Circuit Protection | Yes |
| Over Temperature Protection | No |
| Over Current Protection | Yes |
| Over Voltage Protection | No |
| Under Voltage Protection | Yes |
| Working Temperature Range | -30 to +50 °C |
| Working Humidity Range | 10-50% |
| Storage Temperature Range | -40 to +80 °C |
| Standard Certification | EN 61000-3-2, EN 61000-3-3, EN55024, GB/T 13722-92, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-29, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, YD/T 732-95 |
