NovaStar VX1000 Pro All-in-One LED Display Controller (Upgrade Version of VX1000)

The controller offers a comprehensive suite of input ports to handle numerous content sources including one HDMI 2.0 input with loop out (supporting 8/10/12bit inputs up to 4096×2160@60Hz), two HDMI 1.3 inputs (up to 1920×1080@60Hz), one 3G-SDI input with loop out, and a front-facing USB 3.0 playback (supporting various media formats up to 3840×2160@60Hz). This makes it perfect not only for live events, but also for any sophisticated signage applications.

With ten Gigabit Ethernet ports, it manages up to 6.5 million pixels with output resolutions of up to 10,240 pixels in width or 8,192 pixels in height. This ensures consistent and reliable performance for expanded and large-scale digital LED screens.

Depending on fiber modules type, the device provides both single-mode (with transmission distances up to 10 kilometers) and multi-mode (up to 300 meters) high-speed noise-free data transfer, without signal loss thanks to its two 10G optical fiber ports. The OPT1 port is a self-adaptive, configurable as either a video output when paired with a fiber optic converter (Check NovaStar CVT10 and CVT4K), or a video input port, while OPT2 copies or backs up the output on 10 Ethernet ports or functions as output loop. Please Note: optical modules are not included with the processor and must be purchased separately (Check NovaStar 10G Single-Mode and 10G Multi-Mode SFPs available here in SinaPlug)

In addition to the ability to create unique screen arrangements without being restricted by traditional rectangular designs -which is especially helpful for creative LED displays, stage configurations, and personalized video walls- it allows you to combine custom screen layouts and multiple LED cabinets into a seamless display. Output synchronization is guaranteed across all connected devices via an internal input source or external Genlock.

Users can simply have up to six independent layers (such as 1×4K×1K + 2×2K×1K, or 6×2K×1K), with full control to adjust each layer’s priority, size, position and aspect ratio. This empowers users to easily set up and manage even the most complex and diverse display arrangements.

Rest assured, while you enjoy your 256 user-defined presets simply ready to be loaded; the controller automatically backs up and restores all settings, even after a power loss. It also guarantees data saving by offering multiple backup features like backup between devices, input sources, Ethernet ports, and optical fiber ports.

Engineered for environmental resilience, the system functions optimally in ambient temperatures from 0°C to +50°C. It operates on a 100-240VAC input, with a maximum power consumption of 43W. Its advanced video processing and array of exceptional features position VX1000Pro as an optimal solution for fine-pitch LED displays, complex stage control systems, and high-demand rental environments where continuous 24/7 operation and robust stability (with industrial-grade casing) are essential requirements.

Key Features of NovaStar VX1000 Pro

Up to 6,500,000 pixels

Maximum width: 10,240 pixels / Maximum height: 8,192 pixels

1x HDMI 2.0 (IN & LOOP)

2x HDMI 1.3

1x 3G-SDI ports (IN & LOOP)

1x USB 3.0 port (media playback)

1x Audio input 3.5mm connector

10x Gigabit Ethernet ports

2x 10G optical ports (OPT1: Input/Output/Loop-In, OPT2: Output/Backup/Loop-Out)

1x HDMI 1.3 (for monitoring display)

1x 3D connector (to a 3D emitter)

1x Audio output 3.5mm connector

2x Ethernet (device control and I/O of cascading)

1x GENLOCK IN-LOOP ports

1x USB Type-A port (for updating the firmware)

1x USB Type-B port (to the PC with NovaLCT)

1x RS232 3-pin connectors (RX, TX, G)

1x Light sensor connector (for automatic screen brightness adjustment)

Powerful video processing (SuperView III)

Supports Pixel level brightness, Chroma Calibration, and Color adjustments

High bit-depth inputs (8bit/10bit/12bit) supported

Adaptive to inputs with decimal frame rates

Support audio input (with HDMI and 3.5mm port) and adjustable output volume (through 3.5mm port)

U-disk plug and play with various transition effect of image switching

Supports 3D function

Low Latency

Supports up to 6 layers (adjustable in size, position, and priority)

No Rectangle Restriction (Free topology supporting complex screen configurations)

Multiple kinds of image scaling modes (full screen, pixel to pixel and custom)

supports multiple kinds of End-to-End backups (between devices, Ethernet ports, optic fiber ports, and input sources)

Up to 256 user-defined presets can be saved and loaded easily
