Black Box ServSwitch Fiber KVM Extender II-SM
$5,300.80
Out of stock
Can't find what you need or is it out of stock? Contact us!
We'll source whatever you need according to your timeline and provide our most competitive offer.
US Stock
Same-day shipping or store pickup
Easy Returns
60-day no-questions-asked return
Free Phone Support
Free online technical assistance
The Black Box ServSwitch Fiber KVM Extender II-SM (ACS251A) is a top-notch, single-mode fiber optic KVM (Keyboard, Video and Mouse) extender made to send digital video, keyboard, mouse, and sound waves over up to 10 kilometers (6.2 miles). Engineered for challenging and professional workspaces, it delivers reliable and clear digital connection between a controlling computer (CPU) or a data center and a remote control station, even in loud electromagnetic environments.
The extender uses Duplex single-mode fiber (9/125 µm) to cut down on electrical cable needs, with just a single pair of low-cost fiber optic cables the digitalized serial video/audio signals will be transmitted (with rates up to 1.5Gbps) toward the controlling peripheral devices, after demodulation in remote ACS251A, the mouse and keyboard information will be transmitted back to the CPU unit over the other line of fiber.
Not only are many VGA-compatible video standards supported (such as DOS mode, VGA, XGA, SVGA, and SXGA), but the device can also provide video quality up to 1280×1024 at 75 Hz. Additionally, it supports connection to PS/2 keyboard/mouse, speaker, and monitor. With strong aluminum case and adequate operating temperature range (10 to 40˚C), the II-SM is a great choice for control rooms, data hubs, data centers.
Additionally, a local user station (keyboard, monitor, and mouse) can be connected to the local unit device (CPU side) as an optional feature. This local device switches the keyboard, mouse and video signals and sends them to the remote control station.
Key Features of Black Box ServSwitch Fiber KVM Extender II-SM
Data Transmission Distance
- up to 10 Km (over 9/125-µm single-mode fiber)
Connection
- Electrical (with the CPU unit and local/remote peripheral devices)
- Optical (between local and remote extender units)
I/O Ports
- 1 x SC female pair (optical)
- 2 x 6-pin mini-DIN female (for keyboards and mice)
- 1 x HD15 female (monitor)
- 1 x 3.5-mm stereo audio jack
- 1 x 2.1-mm barrel jack (power)
- 1 x 8-pin mini-DIN
supported resolutions/formats
- Supports many VGA video standards (DOS mode, VGA, XGA, SVGA, or SXGA)
- Supports resolutions up to 1280×1024 and refresh rates up to 75 Hz;
Powering
- 100 to 264VAC adapter (12 VDC, 2.5 amps)
- Local unit power consumption: 14W
- Remote unit power consumption: 12W
Dimensions (LxWxH)
- 66 mm x 185 mm x 180 mm
| Weight | 2.161 lbs |
|---|---|
| Dimensions | 7.68 × 7.48 × 3.15 in |
| Optic Fiber | 1 |
| Max Transmission Distance Meter | 10000 |
| Input Voltage Range | 100-264VAC |
| Max Power Consumption | 14W |
| Working Temperature Range | 10 °C to +40 °C |
| Others | “Supports many VGA video standards (DOS mode, VGA, XGA, SVGA, or SXGA) Supports resolutions up to 1280×1024 and refresh rates up to 75 Hz The adapter can also be 12VDC, 2.5A” |
