Colorlight X4m LED Video Controller
$340.40
1 in stock
In Stock – Ships Today from Carrollton, TX
US Stock
Same-day shipping or store pickup
Easy Returns
60-day no-questions-asked return
Free Phone Support
Free online technical assistance
Are you a Colorlight X2m fan looking to scale up your LED setup? AzarPixel is proud to offer the Colorlight X4m, which features the same advanced processing and signal management as the X2m you already trusted, while including two more Ethernet outputs to handle larger screen configurations compared to the X2m.
This device can handle a maximum loading capacity of 2.6 million pixels, designed for users who value the professional practical features of the X2m, but require a much higher loading capacity. It supports a custom resolution of up to 3840 pixels in width or 2000 pixels in height, delivering an outstanding visual experience for a variety of professional LED applications.
The X4m comes with a wide range of input signals along with USB playback capability, including dual HDMI 1.4, DVI, VGA, and CVBS ports providing flexible connectivity to diverse video sources with maximum resolution of up to 1920×1080@60Hz.
It integrates powerful video processing and control into a single unit and offers screen customization including sharpness, brightness, chroma, and contrast adjustments, in addition to the advanced clipping, scaling, and seamless switching across multiple sources. This device also features precise color management and enhanced grayscale at low brightness for professional-grade performances.
The X4m’s CCC, FCC, CE, and UKCA certifications guarantee flawless continuous operation. It operates reliably in temperatures from -20°C to 65°C, and simplifies the controlling of demanded LED displays by supporting both RS232 (for central system integration) and USB Type-A interfaces (for direct PC configuration), making it a perfect solution for live events, digital signage, and high-end conference applications.
We are an independent reseller of genuine Colorlight products. We are not affiliated with, endorsed by, or sponsored by Colorlight Cloud Tech Ltd. The Colorlight name and logo are trademarks of their respective owner and are used solely to identify the genuine products offered for sale.
Key Features of X4m
Loading Capacity
- Up to 2,600,000 pixels
Input
- 2× HDMI 1.4 (up to 1920×1080@60Hz)
- 1× DVI (up to 1920×1080@60Hz)
- 1× VGA (up to 1920×1080@60Hz)
- 1× CVBS (PAL/NTSC)
- 1× USB (U-disk playback, up to 1920×1080@30Hz)
- 1× 3.5mm Audio input
Output
- 4x Gigabit Ethernet ports
- 1x 3.5mm Audio output (supports HDMI and U-Disk audio)
Control
- 1x RS232 port (RJ11, central control)
- 1x USB 2.0 Type-B port (connecting to a PC)
Preset Resolutions
- HDMI 1.4/DVI: 1920×1080 @ (23.98, 24, 25, 29.97, 30, 50, 59.94, 60, 100, 120) Hz
- VGA: 1920×1080@60Hz
Advanced Features
- Redundant Ethernet output supported
- Free switching, clipping and zooming
- Supports screen offset
- Converts Limit Range to Full Range input color space
- Supports send and read back screen correction factor, advanced stitching
- Precise Color Management
- 16 scene presets
- improved gray level at low brightness
- Independent Audio input and HDMI audio decoding
- Adaptive to decimal frame frequencies
- U-disk playback
Dimensions (L*W*H)
- 483mm * 292mm * 51mm
| Weight | 9.16 lbs |
|---|---|
| Dimensions | 21.02 × 14.02 × 3.5 in |
| Max Input Resolution | 1920×1080@60Hz |
| Supported Resolutions For Input | 1920×1080@60Hz |
| Pixel Capacity | 2.600.000 |
| Max Height Resolution | 2000 |
| DVI In | 1 |
| HDMI In | 2 |
| VGA In | 1 |
| CVBS | 1 |
| Ethernet LED Out | 4 |
| RS232 | 3 |
| Control USB Port | 1 |
| Audio In | 1 |
| Net Weight Kg | 3.13 |
| Gross Weight Kg | 4.16 |
| Input Voltage Range | 100-240VAC |
| Max Power Consumption | 10W |
| Working Temperature Range | -20 to +60 °C |
| USB Playback | Supported |
| Image Decoding | JPG, JPEG, BMP, PNG |
| Standard Certification | CCC, CE, FCC, UKCA |
| Others | Backup Support (Ethernet Ports), Frame Rate Adaptive, Improved Gray Level at Low Brightness, Screen Offset, U-Disk Playback |
