MEAN WELL RSP-320-3.3 Power Supply (3.3V, 60A)
$51.80
51 in stock
| Minimum Qty | Discount |
|---|---|
| 15 + | 3% |
| 30 + | 5% |
| 45 + | 7% |
In Stock – Ships Today from Carrollton, TX
US Stock
Same-day shipping or store pickup
Easy Returns
60-day no-questions-asked return
Free Phone Support
Free online technical assistance
The MEAN WELL RSP-320-3.3 power supply is a remarkable, enclosed power supply ideal for industrial applications, A/V and LED equipment, and Radio Frequency applications that require constant and reliable performance, owing to its ±1.5% load regulation.
This AC/DC, compact RSP-320-3.3 converts wide-range 100-240 VAC inputs, to three consistent output channels at 3.3V with an adjustable 2.97-3.8V range, delivering up to 60A. It provides a rated 198W output power and contains a PFC function that improves overall efficiency (up to 79.5%) for optimal operation.
The key advantages of Meanwell, a leading brand in AC/DC power supplies, are their high reliability and stable operation, compact and space-saving design, long lifespan, and vibration resistance, ensuring consistent performance in tough environments, all at a competitive price
Similar products: MEAN WELL RSP-320-5 Switching Power Supply and MEAN WELL RSP-200-5 Switching Power Supply
In addition to the advanced protections such as overload and over temperature protections (with automatic recovery), overvoltage and short circuit protections, The RSP-320-3.3’s automated speed control built-in fan ensures long-term operation performance in demanding conditions ranging from -30°C to +70°C.
The RSP-320 series is certified by RoHS Directive 2011/65/EU amended by 2015/863 Compliant, UL62368-1, IEC60950-1, EN IEC61000-3-2, EN62368, GB17625, EN55032, and EN55035, permitting it to meet worldwide power standards.
Key Features Of Mean Well RSP-320-3.3 Power Supply
- Type of Power Supply: AC to DC
- Packaging: Enclosed
- Input Voltage Range: 100 – 240VAC
- Adjustable Output Voltage: Yes (2.97 – 3.8V)
- Output Voltage: 3.3V
- Output Rated Current: 60A
- Output Rated Power: 198W
- Protections: Over Temperature, Over Voltage, Over Current Protection, Short Circuit Protection
- Dimensions (L*W*H): 215mm * 115mm * 30m
| Weight | 2.2 lbs |
|---|---|
| Dimensions | 8.46 × 4.53 × 1.18 in |
| Input Voltage Range | 100-240V |
| Input Frequency Range | 47-63Hz |
| Input Current | ≤4A |
| Efficiency | 79.5% |
| Output Voltage | 3.3V |
| Adjustable Output Voltage | Yes |
| Output Rated Current | 60A |
| Output Rated Power | 198W |
| Max Ripple And Noise | 100 mVp-p |
| Output Voltage Tolerance | 2% |
| Short Circuit Protection | Yes |
| Over Temperature Protection | Yes |
| Over Current Protection | Yes |
| Over Voltage Protection | Yes |
| Under Voltage Protection | No |
| Working Temperature Range | -30 to +70 °C |
| Working Humidity Range | 20-90% |
| Storage Temperature Range | -40 to +85 °C |
| Standard Certification | EN55035, EN61558-1, EN62368, GB 4943.1, IEC60950-1, UL62368-1 |
