Huidu HD-KV210 LED Display Controller
$170.70
1 in stock
In Stock – Ships Today from Carrollton, TX
US Stock
Same-day shipping or store pickup
Easy Returns
60-day no-questions-asked return
Free Phone Support
Free online technical assistance
The HD-KV210 from Huidu serves as a flexible and cutting-edge LED video processor. AzarPixel distributes this device, which supports a wide range of display setups (from rental events to permanent installations). It meets most of the demanding requirements of LED to display users by offering flexible screen topology mapping, smooth video cropping, and scaling capabilities.
This processor delivers 1.3 million pixels with a maximum width of 3840 pixels or 2500 pixels in height. It allows arbitrary switching between two synchronous HDMI 1.4 input sources (up to 1920×1080p@60Hz) and its USB type-A supports flawless synchronous playback, resulting in detailed and dynamic contents.
Its output covers two Gigabit Ethernet ports and ensures dependable top-notch data distribution for artistic and commercial LED setups. and the 3.5mm audio output ensures that audio and video signals are synchronized.
The device enables simple and reliable display control via controlling PC connection (USB Type-B port) and dedicated control keys, which also allow users to switch between input sources or manually adjust screen brightness for faster and more convenient operation.
The compact design and versatile compatibility with various LED display configurations make the HD-KV210 a budget-friendly option for professional video wall projects.
Key Features of HD-KV210
Loading Capacity
- Up to 1,300,000 pixels (max width: 3840, max height: 2500)
Input
- 2x HDMI 1.4 (Max. 1920×1080p@60Hz resolution)
- 1x USB 2.0 (for media playback with Max. 1920×1080@30H resolution)
Output
- 2x Gigabit Ethernet Port
- 1x audio output
Control
- 1x USB Type B port (connects to control computer for display control)
Decoding
- Supports the following file formats:
- Image: JPG/JPEG/BMP/PNG
- Video: MP4/AVI/MPG/MOV/VOB/RMVB
Advanced Features
- Video signals support switching, cropping, scaling, and zooming
- Supports manual brightness adjustment
- Audio synchronization
Dimensions (L*W*H)
- 248mm * 132mm * 42mm
| Weight | 3 lbs |
|---|---|
| Dimensions | 12.8 × 11.81 × 3.15 in |
| Max Input Resolution | 1920×1080@60Hz |
| Supported Resolutions For Input | 1920×1080@60Hz, 1920×1080p@30Hz |
| Pixel Capacity | 1.300.000 |
| Max Height Resolution | 2500 |
| HDMI In | 2 |
| Ethernet LED Out | 2 |
| Control USB Port | 1 |
| Audio Out | 1 |
| Cascading | No |
| Net Weight Kg | 0.7 |
| Gross Weight Kg | 1.3 |
| Input Voltage Range | 12VDC |
| Max Power Consumption | 14W |
| Working Temperature Range | -20 °C to +55 °C |
| USB Playback | Supported |
| Image Decoding | JPG, JPEG, BMP, PNG |
| Video Decoding | MP4, AVI, MPG, MKV, MOV, VOB, RMVB, MPEG4 (MP4), MPEG_SD/HD, H.264 (AVI, MKV), FLV |
| Others | Brightness Adjustment, Video Cropping, Video Scaling, Video Signal Switching |
