Linsn TS902 Sending Card
$199.90
10 in stock
In Stock – Ships Today from Carrollton, TX
US Stock
Same-day shipping or store pickup
Easy Returns
60-day no-questions-asked return
Free Phone Support
Free online technical assistance
Azarpixel is now pleased to offer the Linsn TS902 Sending Card, a flexible and powerful sending card that supports a remarkable 2.6 million pixels, making it capable of driving extensive single, double, and full-color LED screens with outstanding clarity.
The card supports up to 4K video source inputs in addition to handling 8bit/10bit/12bit depth video inputs, and also an impressive 16-bit grey scale, delivering detailed visuals for a truly enriched viewing experience. This card takes in both DVI and HDMI, which means sharp images and wide use in many fields.
Linsn TS902 Sending Card features four network output ports and includes advanced functions such as RCG file read-back, RCG file broadcasting, and CON file broadcasting, which allow for quick configuration backups.
It also has audio input and one USB (Type-B) for configuration and controlling, and works well with all kinds of full-color LED displays.
Key Features of Linsn TS902
Loading Capacity
- Up to 2,600,000 pixels
Input
- 1x DVI input connector
- 1x HDMI input connector
- 1x Audio input
- Supports up to 4K video source
Output
- 4x Gigabit Ethernet outputs (up to 2560×1024 resolutions)
Control
- 1x USB (Type B) interface
Performance
- Supports video resolutions 2560×1024, 1920×1200, 2048×1152
- Supports broadcasting and reading back configuration (CON) and parameter (RCG) files
- 8-bit/10-bit/12-bit video input;
- 16-bit grayscale display supported
- PCI-E 1X slot
Dimensions (L*W*H):
- 142mm * 120mm * 40mm
| Weight | 0.93 lbs |
|---|---|
| Dimensions | 9.09 × 5.87 × 2.17 in |
| Ethernet Port | 4 |
| Max Pixel Capacity | 2,600,000 |
| Supported Resolutions For Input | 1920×1200@60Hz, 2048×1152@60Hz, 2560×1024@60Hz |
| HDMI In | 1 |
| DVI In | 1 |
| Audio In | 1 |
| Supported Video Source Bit Depth | 8bit, 10bit, 12bit |
| Configuration Parameters Backup and Readback | Supported |
| Input Voltage Range | 4.5-5.5VDC |
| Max Power Consumption | 3.1W |
| Working Temperature Range | -20 to +70 °C |
| Others | “Supports 4k resolutions 16-Bit Grayscale” |
