MRV532 Receiving Card
$40.40
15 in stock
| Minimum Qty | Discount |
|---|---|
| 5 - 10 | 3% |
| 11 - 20 | 6% |
| 20 - 99 | 9% |
| 100 + | 10% |
In Stock – Ships Today from Carrollton, TX
US Stock
Same-day shipping or store pickup
Easy Returns
60-day no-questions-asked return
Free Phone Support
Free online technical assistance
AzarPixel is pleased to offer MRV532 receiving card, built to deliver high performance, rich image processing features, and rock-solid stability for modern LED display systems. Supporting a maximum resolution of up to 512×512 pixels @60Hz and advanced functions such as HDR, 18bit+ grayscale enhancement, color management, and low latency, it helps produce smooth, detailed, and vibrant visuals across a wide range of applications. With support for up to 40 groups of RGB data via 10 HUB320F connectors (26-Pin), it offers flexible compatibility with high-density LED modules while keeping wiring reliable and organized.
It has pixel-level brightness and chroma calibration, individual gamma adjustment for each RGB channel, and fast seam correction for dark or bright lines at module or cabinet joins, enhancing uniformity across the entire screen. Besides, it features 3D, 90° image rotation, and multi-batch brightness adjustment, making it well-suited for high-end installs that require accurate color, deep contrast, and consistent brightness. Designed to operate in harsh environments, the MRV532 works reliably from –20°C to +70°C with wide humidity tolerance, and it integrates real-time temperature and voltage monitoring without extra sensors for added protection.
For maintenance and diagnostics, this receiving card provides bit error detection, Ethernet link quality monitoring, configuration and firmware readback, and a self-test button that can trigger on-screen test patterns (when the data link is disconnected). Reliability is further improved through loop backup, dual NCP backup, and dual storage of configuration parameters so that communication or configuration faults are less likely to interrupt playback. Compact dimensions, low power consumption around 2.5 W, and support for cabinet LCDs make integration straightforward in both new and retrofit LED projects.
The MRV532 is ideal for fine-pitch indoor and high-end commercial LED applications such as retail videowalls, command centers, broadcast sets, and corporate signage where image quality, calibration capability, and stability are critical. Its RoHS and EMC Class A certificates, make it a reliable backbone for LED integrators and manufacturers looking to standardize on a versatile, next-generation receiving card platform.
Azar Pixel, LLC is an independent reseller and is not affiliated with, authorized by, sponsored by, or endorsed by NovaStar Tech Co., Ltd. NOVASTAR® is a registered trademark of its respective owner and is used solely for product identification purposes. This product is sold without a NovaStar U.S. manufacturer warranty. Any warranty, if offered, is provided solely by Azar Pixel, LLC.
Key Features of NovaStar MRV532
Loading Capacity
- For PWM driver ICs (By M3 controllers):
- 512×512 pixels @60Hz (For 8-bit video sources)
- 512×384 pixels @60Hz (For 10-bit and 12-bit video sources)
- For PWM driver ICs (By COEX controllers):
- 512×512 pixels @60Hz (For 8-bit and 10-bit video sources)
- 512×384 pixels @60Hz (For 12-bit video sources)
- For common driver ICs (By M3 controllers):
- 512×384 pixels @60Hz (For 8-bit video sources)
- 256×384 pixels @60Hz (For 10-bit and 12-bit video sources)
- For common driver ICs (By COEX controllers):
- 512×384 pixels @60Hz (For 8-bit and 10-bit video sources)
- 256×384 pixels @60Hz (For 12-bit video sources)
Input
- 1x Gigabit Ethernet Port
Output
- 10× standard 26-Pin HUB320F module connectors (Up to 40 groups of RGB real-pixel, 40 groups of 3‑LED sub-pixel or 30 groups of 4‑LED sub-pixel data)
- 1x Gigabit Ethernet Port
Performance
- Pixel Level brightness and chroma calibration
- Individual gamma adjustment for each RGB channel
- 18bit+ grayscale enhancement for smoother low-brightness performance
- HDR support (with compatible controller and workflow)
- Multi-batch brightness adjustment
- 3D function support
- Image rotation in 90° increments
- Quick adjustment of dark and bright lines at module/cabinet joins
Features
- Maintainability:
- Mapping 1.1 function
- Quick uploading of calibration coefficients
- User-settable pre-stored image for no signal or startup scenarios
- Real-time temperature and voltage monitoring without extra peripherals
- Cabinet LCD support
- Bit error detection and Ethernet cable communication status monitoring
- Configuration parameter and firmware readback support
- Reliability:
- Loop backup for redundant communication between the controller and receiving cards
- Dual NCP backup to enhance system stability (controller-dependent feature)
- Dual backup of configuration parameters
Dimensions (L*W*H)
- 146mm * 92mm * 19mm
| Weight | 0.22 lbs |
|---|---|
| Dimensions | 7.48 × 5.91 × 0.79 in |
| Max PWM IC Pixel Capacity | 512×512 |
| Max Common IC Pixel Capacity | 512×384 |
| Output Interface (QTY) | 10 |
| Max Parallel RGB Data Groups | 40 |
| Supported Video Source Bit Depth | 8bit, 10bit, 12bit |
| HDR Function | Supported |
| Brightness and Chroma Calibration | Supported |
| 90° Image Rotation | Supported |
| Loop Backup | Supported |
| Bit Error Detection | Supported |
| Dual Configuration Parameters Backup | Supported |
| Firmware Redundancy and Readback | Supported |
| Input Voltage Range | 3.8-5.5VDC |
| Max Power Consumption | 2.5W |
| Working Temperature Range | -20 °C to +70 °C |
| Standard Certification | EMC Class A, RoHS |
| Others | Automatic module calibration uploading of module calibration coefficients, Color Management, Dual NCP Backup, Individual Gamma Adjustment for RGB, Low Latency, Module Flash management, Multi-batch Adjustment, Settings of a Stored Image in the Receiving Card, Supports temperature and voltage monitoring |
